2" Helical Rotor Solar Pump

Series: 2SPS · RN2S

A slim 2-inch helical-rotor pump for narrow boreholes where depth is the challenge — ideal for household drinking water and remote points.

Key features

Helical rotor — high head, steady low flow
Stainless-steel construction
Dry-run & full electronic protection
Matched WIKKIES MPPT controller

Typical specifications

Model / Series	2SPS · RN2S
Models	6 models
Power	80 – 750 W
Max head	up to 120 m
Max flow	up to 2 m³/h
Outlet	0.5″
Panel input	DC 12 – 72 V

Specifications are representative ranges. Exact model specifications are confirmed on quotation to suit your site.

Request a Quote Call 012 333 8722

Product Details

What the 2SPS · RN2S Offers

Typical Applications

Household & village drinking water
Livestock & game watering
Agriculture & drip irrigation
Fountains & garden watering
Remote & off-grid water supply

Advantages & Protection

MPPT — Maximum Power Point Tracking
RMS — Remote Monitoring System (optional)
Adjustable pump speed
Dry-run protection
Over- / under-voltage protection
Over- / under-current protection
Over-temperature protection (max 88°C)
Reverse-polarity / reverse-wiring protection
Soft start & soft stop
LCD display of all live data
Automatic stop / restart on water level
Wireless water-level detector option (up to 3 km)

Build & Materials

Motor windings	100% copper
Helical rotor	AISI 304 stainless steel
Silicon steel	Cold-rolled
Pump body & shaft	AISI 304 stainless steel
Bearings	C&U / NSK
Outlet	AISI 304 stainless steel
Mechanical seal	NBR
Seal lubricant	Food-grade oil

Motor: Maintenance-free brushless DC (BLDC) motor with integrated DSP & MPPT, dry-running protection, battery operation with low-voltage disconnect, and overload / high-temperature protection.

Free accessories: water-level sensors, cable connector, spared rotor and ropes.

Technical Data

Full Model Range — 2SPS · RN2S

Complete series specifications and matched solar array.

Model	Volt (V)	Power (W)	Power (HP)	Max Flow	Max Head	Outlet	Recommended Solar Panel
2SPS0.9/32-12/80	12	80	0.10	0.9m³/h	32m	0.5"	1 × 200 W · 36 V
2SPS1.3/50-D24/140	24	140	0.20	1.3m³/h	50m	0.5"	1 × 300 W · 36 V
2SPS1.6/80-D24/210	24	210	0.30	1.6m³/h	80m	0.5"	1 × 300 W · 36 V
2SPS1.8/100-D36/270	36	270	0.40	1.8m³/h	100m	0.5"	1 × 400 W · 36 V
2SPS1.8/110-D48/500	48	500	0.75	1.8m³/h	110m	0.5"	2 × 400 W · 36 V
2SPS2/120-D72/750	72	750	1.00	2.0m³/h	120m	0.5"	2 × 550 W · 41 V
